Goodrive200 inverters
Appendix C
259
C.7.2 Filters selection table
The inverter Input filter Output filter
GD200-1R5G-4
FLT-P04006L-B FLT-L04006L-B
GD200-2R2G-4
GD200-004G/5R5P-4
FLT-P04016L-B FLT-L04016L-B
GD200-5R5G/7R5P-4
GD200-7R5G/011P-4
FLT-P04032L-B FLT-L04032L-B
GD200-011G/015P-4
GD200-015G/018P-4
FLT-P04045L-B FLT-L04045L-B
GD200-018G/022P-4
GD200-022G/030P-4
FLT-P04065L-B FLT-L04065L-B
GD200-030G/037P-4
GD200-037G/045P-4
FLT-P04100L-B FLT-L04100L-B
GD200-045G/055P-4
GD200-055G/075P-4
FLT-P04150L-B FLT-L04150L-B
GD200-075G/090P-4
GD200-090G/110P-4
FLT-P04240L-B FLT-L04240L-B
GD200-110G/132P-4
GD200-132G/160P-4
GD200-160G/185P-4
FLT-P04400L-B FLT-L04400L-B
GD200-185G/200P-4
GD200-200G/220P-4
GD200-220G/250P-4
FLT-P04600L-B FLT-L04600L-B
GD200-250G/280P-4
GD200-280G/315P-4
GD200-315G/350P-4
FLT-P04800L-B FLT-L04800L-B
GD200-350G/400P-4
GD200-400G-4
GD200-500G-4 FLT-P041000L-B FLT-L041000L-B
Note: The input EMI meet the requirement of C2 after adding input filters.
C.8 Braking system
C.8.1 Select the braking components
It is appropriate to use braking resistor or braking unit when the motor brakes sharply or the
motor is driven by a high inertia load. The motor will become a generator if its actual rotating
