Goodrive200 inverters Basic operation instruction
161
Function
code
Name
Detailed instruction of parameters Default
value
P08.43
K
eypad data potentiometer
integral ratio
0.01~10.00s 0.10s
P08.44
UP/DOWN terminals
control
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting valid
1:UP/DOWN terminals setting valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:All frequency means are valid
2:When the multi-step are priority, it is
invalid to the multi-step
LED hundreds: action selection when
stop
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after
receiving the stop commands
0x000
P08.45
UP terminals frequency
increasing integral ratio
0.01~50.00Hz/s 0.50 Hz/s
P08.46
DOWN terminals
frequency integral ratio
0.01~50.00 Hz/s 0.50 Hz/s
P17.00
Set frequency
0.00Hz~P00.03
(the Max. output frequency)
0.00Hz
P17.02
Ramp reference frequency
0.00Hz~P00.03
(the Max. output frequency)
0.00Hz
P17.14 Digital adjustment 0.00Hz~P00.03 0.00Hz
7.9 Analog input
Goodrive200 series inverters have three analog input terminals and 1 high-speed pulse input
terminals (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input
by J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
