INVT GD200-037G/045P-4 - Name Plate

Goodrive200 inverters Product overview
15
Function Specification
Temperature of the
running environment
-10~50℃, derate above 40℃
Ingress protection IP20
Cooling Air-cooling
Braking unit
Built-in braking unit for inverters below 30kW
(including 30kW)
External braking unit for others
EMC filter
Built-in C3 filter: meet the degree requirement of
IEC61800-3 C3
External optional filter:meet the degree requirement
of IEC61800-3 C2
3.4 Name plate
Fig 3-3 Name plate
Note: This is the example of the name plate for the standard products, and CE\TUV\IP20 will
be marked according to the actual situations.
