Goodrive200 inverters
Appendix C
257
The power of the inverter
Input reactor DC reactor Output reactor
GD200-030G/037P-4 ACL2-030-4 / OCL2-030-4
GD200-037G/045P-4 ACL2-037-4 DCL2-037-4 OCL2-037-4
GD200-045G/055P-4 ACL2-045-4 DCL2-045-4 OCL2-045-4
GD200-055G/075P-4 ACL2-055-4 DCL2-055-4 OCL2-055-4
GD200-075G/090P-4 ACL2-075-4 DCL2-075-4 OCL2-075-4
GD200-090G/110P-4 ACL2-090-4 DCL2-090-4 OCL2-090-4
GD200-110G/132P-4 ACL2-110-4 DCL2-110-4 OCL2-110-4
GD200-132G/160P-4 ACL2-132-4 DCL2-132-4 OCL2-132-4
GD200-160G/185P-4 ACL2-160-4 DCL2-160-4 OCL2-160-4
GD200-185G/200P-4 ACL2-200-4 DCL2-200-4 OCL2-200-4
GD200-200G/220P-4 ACL2-200-4 DCL2-200-4 OCL2-200-4
GD200-220G/250P-4 ACL2-250-4 DCL2-280-4 OCL2-250-4
GD200-250G/280P-4 ACL2-250-4 DCL2-280-4 OCL2-250-4
GD200-280G/315P-4 ACL2-280-4 DCL2-280-4 OCL2-280-4
GD200-315G/350P-4 ACL2-315-4 DCL2-315-4 OCL2-315-4
GD200-350G/400P-4 Standard DCL2-350-4 OCL2-350-4
GD200-400G-4
Standard
DCL2-400-4 OCL2-400-4
GD200-500G-4
Standard
DCL2-500-4 OCL2-500-4
Note:
1. The rated derate voltage of the input reactor is 2%±15%.
2. The power factor of the input side is above 90% after adding DC reactor.
3. The rated derate voltage of the output reactor is 1%±15%.
4. Above options are external, the customer should indicate when purchasing.
C.7 Filters
Goodrive200 series inverters have embedded C3 filters which can be connected by J10.
