Goodrive200 inverters Basic operation instruction
183
Function
code
Name Detailed instruction of parameters
Default
value
P05.01~
P05.09
Digital input function
selection
23:Simple PLC stop reset
24:Simple PLC pause
P06.01~
P06.04
Digital output function
selection
15: Underload pre-alarm
16:Completion of simple PLC step
P17.00 Set frequency
0.00Hz~P00.03
(the Max. output frequency)
0.00Hz
P17.27
Simple PLC and the
current step of the
multi-step speed
7.14 Multi-step speed running
Set the parameters when the inverter carries out multi-step speed running. Goodrive200 series
inverters can set 16 step speed which can be selected by the combination code of multi-step
speed terminals 1~4. They correspond to multi-step speed 0 to 15.
