INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
167
Function
code
Name
Detailed instruction of parameters Default
value
output to the upper limit
P06.31 HDO output filter time 0.000s~10.000s 0.000s
7.11 Digital input
Goodrive200 series inverters have 8 programmable digital input terminals and 1 open-collector
input terminal in the standard configuration. All functions of the digital input terminals are
programmable by the function codes. Open collector pole input can be selected into high speed
pulse input terminal or common switch input terminal by function code. When selected into HDI,
the user can select HDI high speed pulse input as frequency reference, counting input or length
pulse input by setting.
