INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
166
Function
code
Name
Detailed instruction of parameters Default
value
9:Output torque
10:Analogy AI1 input value
11:Analogy AI2 input value
12:Analogy AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16~21:Reserved
22: Torque current (the rated current of
the motor)
23: Ramp reference frequency(with sign)
24~30: Reserved
P06.17 Lower limit of AO1
output
0.0%~P06.15 0.0%
P06.18
Corresponding AO1
output to the lower limit
0.00V~10.00V 0.00V
P06.19 Upper limit of AO1 output
P06.13~100.0% 100.0%
P06.20
The corresponding AO1
output to the upper limit
0.00V~10.00V 10.00V
P06.21 AO1 output filter time 0.000s~10.000s 0.000s
P06.22 Lower limit of AO2 output
0.0%~P06.20 0.0%
P06.23
Corresponding AO2
output to the lower limit
0.00V~10.00V 0.00V
P06.24 Upper limit of AO2 output
P06.18~100.0% 100.0%
P06.25
Corresponding AO2
output to the upper limit
0.00V~10.00V 10.00V
P06.26 AO2 output filter time 0.000s~10.000s 0.000s
P06.27 Lower limit of HDO output
0.0%~P06.25 0.00%
P06.28
Corresponding HDO
output to the lower limit
0.00~50.00kHz 0.0kHz
P06.29 Upper limit of HDO output
P06.23~100.0% 100.0%
P06.30 Corresponding HDO 0.00~50.00kHz 50.00kHz
