INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Product overview
17
Model
Constant torque Variable torque
Output
power
(kW)
Input
current
(A)
Output
current
(A)
Output
power
(kW)
Input
current
(A)
Output
current
(A)
GD200-037G/045P-4
37 80 75 45 94 92
GD200-045G/055P-4
45 94 92 55 128 115
GD200-055G/075P-4
55 128 115 75 160 150
GD200-075G/090P-4
75 160 150 90 190 180
GD200-090G/110P-4
90 190 180 110 225 215
GD200-110G/132P-4
110 225 215 132 265 260
GD200-132G/160P-4
132 265 260 160 310 305
GD200-160G/185P-4
160 310 305 185 345 340
GD200-185G/200P-4
185 345 340 200 385 380
GD200-200G/220P-4
200 385 380 220 430 425
GD200-220G/250P-4
220 430 425 250 485 480
GD200-250G/280P-4
250 485 480 280 545 530
GD200-280G/315P-4
280 545 530 315 610 600
GD200-315G/350P-4
315 610 600 350 625 650
GD200-350G/400P-4
350 625 650 400 715 720
GD200-400G-4 400 715 720
GD200-500G-4 500 890 860
Note:
1. The input current of 1.5~315kW inverters is measured when the input voltage is 380V and
no DC reactor and input/output reactor.
2. The input current of 350~500kW inverters is measured when the input voltage is 380V
and the circuit is with input reactor.
3. The rated output current is defined as the output current when the output voltage is 380V.
4. In the allowable voltage range, the output power and current can not exceed the rated
output power and current in any situation.
3.7 Structure diagram
Below is the layout figure of the inverter (take the inverter of 30kW as the example).
