INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Basic operation instruction
163
Function
code
Name Detailed instruction of parameters
Default
value
the upper limit of AI2
P05.41 AI2 input filter time 0.000s~10.000s 0.100s
P05.42
Lower limit of
AI3
-10.00V~P05.35 -10.00V
P05.43
Corresponding setting of
the lower limit of AI3
-100.0%~100.0% -100.0%
P05.44 Middle value of AI3 P05.33~P05.37 0.00V
P05.45
Corresponding middle
setting of AI3
-100.0%~100.0% 0.0%
P05.46 Upper limit of AI3 P05.35~10.00V 10.00V
P05.47
Corresponding setting of
the upper limit of AI3
-100.0%~100.0% 100.0%
P05.48 AI3 input filter time 0.000s~10.000s 0.100s
P05.49
HDI high-speed pulse
input function
selection
0:Fquency setting input
1:Counter input
2:Length counting input
0
P05.50
Lower limit frequency of
HDI
0.000kHz ~ P05.43
0.000
kHz
P05.51
Corresponding setting of
HDI
low frequency setting
-100.0%~100.0% 0.0%
P05.52
Upper limit frequency of
HDI
P05.41 ~50.000kHz
50.000
kHz
P05.53
Corresponding setting of
upper limit frequency of
HDI
-100.0%~100.0% 100.0%
P05.54
HDI frequency input filter
time
0.000s~10.000s 0.100s
7.10 Analog output
Goodrive200 series inverters have 2 analog output terminals (0~10V or 0~20mA) and 1 high speed
pulse output terminal. Analog output signals can be filtered separately and the maximum and
