Goodrive200 inverters Function codes
110
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
magnetic flux braking, while the cooling of the
stator is more effective than the rotor.
P08.51
Input
power
factor of
the inverter
This function code is used to adjust the displayed
current of the AC input side.
Setting range:0.00~1.00
0.56 ○
P09 Group PID control
P09.00
PID
reference
source
When the frequency command selection
(P00.06, P00. 07) is 7 or the voltage setting
channel selection (P04.27) is 6, the running
mode of the inverter is procedure PID controlled.
The parameter determines the target reference
channel during the PID procures.
0:Keypad digital reference(P09.01)
1:Analog channel AI1 reference
2:Analog channel AI2 reference
3:Analog channel AI3 set
4:High speed pulse HDI set
5:Multi-step speed set
6:MODBUS communication set
7~9: Reserved
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the relative
value (0~100.0%).
Note:
Multi-step speed reference, it is realized
by
setting P10 group parameters.
0 ○
P09.01
Keypad
PID preset
When P09.00=0, set the parameter whose basic
value is the feedback value of the system.
0.0% ○
