INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters
Appendix C
253
The inverter
Recommended cable size(mm
2
) Screw
R,S,T
U,V,W
PE P1(+)
PB(+)(-)
Termin
al
screw
size
Tightening
torque
(Nm)
GD200-1R5G-4
2.5 2.5 2.5 2.5 M4 1.2~1.5
GD200-2R2G-4
2.5 2.5 2.5 2.5 M4
1.2~1.5
GD200-004G/5R5P-4
2.5 2.5 2.5 2.5 M4
1.2~1.5
GD200-5R5G/7R5P-4
4 4 2.5 2.5 M5 2-~2.5
GD200-7R5G/011P-4
6 6 4 2.5
M5 2-~2.5
GD200-011G/015P-4
10 10 6 4
M5 2-~2.5
GD200-015G/018P-4
10 10 10 4
M5 2-~2.5
GD200-018G/022P-4
16 16 10 6 M6 4~6
GD200-022G/030P-4
25 16 16 10 M6 4~6
GD200-030G/037P-4
25 16 16 10 M8 9~11
GD200-037G/045P-4
35 16 25 16
M8 9~11
GD200-045G/055P-4
50 25 35 25
M8 9~11
GD200-055G/075P-4
70 35 50 25 M10 18~23
GD200-075G/090P-4
95 50 70 35
M10 18~23
GD200-090G/110P-4
120 70 95 35
M10 18~23
GD200-110G/132P-4
150 70 120 70
M12
31-40
GD200-132G/160P-4
185 95 150 95
M12
31-40
GD200-160G/185P-4
240 95 185 50
M12
31-40
GD200-185G/200P-4
120*2P
150 95*2P
50 M12 31-40
GD200-200G/220P-4
120*2P
150 95*2P
50
M12
31-40
GD200-220G/250P-4
150*2P
150 95*2P
50
M12
31-40
GD200-250G/280P-4
150*2P
150 120*2P
95
M12
31-40
GD200-280G/315P-4
185*2P
185 120*2P
95
M12
31-40
GD200-315G/350P-4
185*2P
185 120*2P
95
M12
31-40
GD200-350G/400P-4
95*4P
95*2P
150*2P
120
M12
31-40
GD200-400G-4
95*4P
95*2P
150*2P
120
M12
31-40
GD200-500G-4
120*4P
95*2P
95*4P
120
M12
31-40
