INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters
Appendix C
261
The inverter
Braking unit
type
100% of
braking
(Ω)
The consumed power of the
braking resistor
Mini
Braking
Resistor
(Ω)
10%
braking
50%
braking
80%
braking
GD200-5R5G/7R5P-4
89 0.75 4.1 6.6 60
GD200-7R5G/011P-4
65 1.1 5.6 9 47
GD200-011G/015P-4
44 1.7 8.3 13.2 31
GD200-015G/018P-4
32 2 11 18 23
GD200-018G/022P-4
27 3 14 22 19
GD200-022G/030P-4
22 3 17 26 17
GD200-030G/037P-4
5 23 36 17
GD200-037G/045P-4
DBU100H-060-4
13 6 28 44 11.7
GD200-045G/055P-4
DBU100H-110-4
10 7 34 54
6.4
GD200-055G/075P-4 8 8 41 66
GD200-075G/090P-4 6.5 11 56 90
GD200-090G/110P-4
DBU100H-160-4
5.4 14 68 108
4.4
GD200-110G/132P-4 4.5 17 83 132
GD200-132G/160P-4
DBU100H-220-4 3.7 20 99 158 3.2
GD200-160G/185P-4
DBU100H-320-4
3.1 24 120 192
2.2
GD200-185G/200P-4 2.8 28 139 222
GD200-200G/220P-4 2.5 30 150 240
GD200-220G/250P-4
DBU100H-400-4
2.2 33 165 264
1.8
GD200-250G/280P-4 2.0 38 188 300
GD200-280G/315P-4
Two
DBU100H-320-4
3.6*2 21*2 105*2 168*2
2.2*2
GD200-315G/350P-4 3.2*2 24*2 118*2 189*2
GD200-350G/400P-4 2.8*2 27*2 132*2 210*2
GD200-400G-4 2.4*2 30*2 150*2 240*2
GD200-500G-4
Two
DBU100H-400-4
2*2 38*2 186*2 300*2 1.8*2
 Never use a brake resistor with a resistance below the minimum value
specified for the particular drive. The drive and the internal chopper are
not able to handle the overcurrent caused by the low resistance.
torque
17
