INVT GD200-037G/045P-4 User Manual

Goodrive200 inverters Function codes
47
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
frequency
frequency.
Setting range:P00.05~P00.03 (Max. output
frequency)
P00.05
Lower limit
of the
running
frequency
The lower limit of the running frequency is that of
the output frequency of the inverter.
The inverter runs at the lower limit frequency if
the set frequency is lower than the lower limit
one.
Note: Max. output frequency ≥ Upper limit
frequency ≥ Lower limit frequency
Setting range:0.00Hz~P00.04 (Upper limit of the
running frequency)
0.00Hz
◎
P00.06
A
frequency
command
Note: Frequency A and frequency B cannot use
the same frequency setting mode. The frequency
source can be set by P00.09.
0:Keypad data setting
Modify the value of P00.10 (set the frequency by
keypad) to modify the frequency by the keypad.
1:Analog AI1 setting
2:Analog AI2 setting
3:Analog AI3 setting
Set the frequency by analog input terminals.
Goodrive200 series inverters provide 3 channels
analog input terminals as the standard
configuration, of which AI1/AI2 are the
voltage/current option (0~10V/0~20mA) which
can be shifted by jumpers; while AI3 is voltage
input (-10V~+10V).
Note: when analog AI1/AI2 select 0~20mA input,
the corresponding voltage of 20mA is 10V.
100.0% of the analog input setting corresponds
0 ○
P00.07
B
frequency
command
2 ○
