Goodrive200 inverters Function codes
50
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
3: A-B, the current frequency setting is A
frequency command - B frequency command
4: Max (A, B): the bigger one between A
frequency command and B frequency is the set
frequency.
5: Min (A, B): The lower one between A
frequency command and B frequency is the set
frequency.
Note:The combination manner can be shifted by
P05(terminal function)
P00.10
Keypad set
frequency
When A and B frequency commands are selected
as “keypad setting”, this parameter will be the
initial value of inverter reference frequency
Setting range:0.00 Hz~P00.03
(the Max. frequency)
50.00
Hz
P00.11
ACC time
1
ACC time means the time needed if the inverter
speeds up from 0Hz to the Max. One (P00.03).
DEC time means the time needed if the inverter
speeds down from the Max. Output frequency to
0Hz (P00.03).
Goodrive200 series inverters define four groups
of ACC/DEC time which can be selected by P05.
The factory default ACC/DEC time of the inverter
is the first group.
Setting range of P00.11 and P00.12:0.0~3600.0s
Depend
on
model
P00.12
DEC time
1
Depend
on
model
P00.13
Running
direction
0: Runs at the default direction, the inverter runs
in the forward direction. FWD/REV indicator is
off.
1: Runs at the opposite direction, the inverter
runs in the reverse direction. FWD/REV indicator
is on.
0
