Goodrive270 series VFD for fan and pump Basic operation guidelines
-94-
Function
code
Name Description Default
103: Manual soft startup for motor H
104: Disable motor A
105: Disable motor B
106: Disable motor C
107: Disable motor D
108: Disable motor E
109: Disable motor F
110: Disable motor G
111: Disable motor H
P05.08 Input terminal polarity 0x00±0x3F 0x00
P05.09 Digital input filter time 0.000±1.000s 0.010s
P05.10 Virtual terminal setting
0x00±0x3F (0: Disable. 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: Reserved
0x00
P05.11 Terminal control mode
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0
P05.12 S1 switch-on delay
0.000±50.000s
0.000s
P05.13 S1 switch-off delay
0.000±50.000s
0.000s
P05.14 S2 switch-on delay
0.000±50.000s
0.000s
P05.15 S2 switch-off delay
0.000±50.000s
0.000s
P05.16 S3 switch-on delay
0.000±50.000s
0.000s
P05.17 S3 switch-off delay
0.000±50.000s
0.000s
P05.18 S4 switch-on delay
0.000±50.000s
0.000s
P05.19 S4 switch-off delay
0.000±50.000s
0.000s
P05.20 HDIA switch-on delay
0.000±50.000s
0.000s
P05.21 HDIA switch-off delay
0.000±50.000s
0.000s
P05.22 Reserved
P05.23 Reserved
