Goodrive270 series VFD for fan and pump Product overview
-11-
3.6 Product ratings
Table 3-1 Ratings for AC 3PH 380V models
VFD model
Output power (kW)
Input current (A)
Output current (A)
GD270-030-4
30
75
60
GD270-037-4
37
90
75
GD270-045-4
45
108
92
GD270-055-4
55
142
115
GD270-075-4
75
177
150
GD270-090-4
90
200
180
GD270-110-4
110
240
215
GD270-132-4
132
278
250
GD270-160-4
160
310
305
GD270-185-4
185
335
330
GD270-200-4
200
385
380
GD270-220-4
220
430
425
GD270-250-4
250
465
460
GD270-280-4
280
485
530
GD270-315-4
315
550
600
GD270-355-4
355
600
650
GD270-400-4
400
660
720
GD270-450-4
450
745
820
GD270-500-4
500
800
860
Note:
The rated output current is the output current when the output voltage is 380V.
Within the allowable input voltage range, the output current/power cannot exceed the rated
output current/power.
The input current of the < 355kW models is measured at an input voltage of 380V and without DC
reactors or input/output reactors.
The input current of the 400±500kW models is measured at an input voltage of 380V and with DC
reactors.
3.7 Structure
The VFD structure is shown in the following figure (taking the 380V 45kW VFD model as an
example).
