INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-86-
Function
code
Name Description Default
24: Set frequency (bipolar)
25: Ramp reference frequency (bipolar)
26: Rotational speed (bipolar)
27: Value 2 set through
EtherCAT/PROFINET/EthernetIP
28: C_AO1 from CODESYS (Set P27.00
to 1.)
29: C_AO2 from CODESYS (Set P27.00
to 1.)
30: Rotational speed
31: Output torque
32: PID1 output
33: PID2 output
34: PID1 reference value
35: PID1 feedback value
36: PID2 reference value
37: PID2 feedback value
38±47: Reserved
P06.17
AO1 output lower limit
-300.0%±P06.19
0.0%
P06.18
AO1 output corresponding to
lower limit
0.00V±10.00V 0.00V
P06.19
AO1 output upper limit
P06.17±300.0%
100.0%
P06.20
AO1 output corresponding to
upper limit
0.00V±10.00V 10.00V
P06.21
AO1 output filter time
0.000s±10.000s
0.000s
P06.22
AO0 output lower limit
-300.0%±P06.23
0.0%
P06.23
AO0 output corresponding to
lower limit
0.00V±10.00V 0.00V
P06.24
AO0 output upper limit
P06.35±300.0%
100.0%
P06.25
AO0 output corresponding to
upper limit
0.00V±10.00V 10.00V
P06.26
AO0 output filter time
0.000s±10.000s
0.000s
P06.27±
P06.31
Reserved
5.5.11 Digital input
The VFD carries four programmable digital input terminals and two HDI input terminals. The function
of all the digital input terminals can be programmed through function codes. HDI input terminal can be
