Goodrive270 series VFD for fan and pump Product overview
-10-
3.4 Product nameplate
Shenzhen INVT Electric Co., Ltd.
Model: GD270-160-4 IP20
Power(Output): 160kW
Input: AC 3PH 380V-480V 310A 47Hz-63Hz
Output: AC 3PH 0V-Uinput 305A 0Hz-400Hz
S/N: Made in China
Figure 3-3 Product nameplate
Note: The preceding shows a standard product nameplate example. The nameplate has
markings such as "CE", "TUV", and "IP20" depending on the actual certification result.
3.5 Model designation code
A model designation code contains product information. You can find the model designation code on
the VFD nameplate and simplified nameplate.
GD270-160-4-L1
ķ ĸ Ĺ
ĺ
Figure 3±4 Model description
Field
Sign
Description
Content
Product
series
abbreviation
ķ
Product series
abbreviation
GD270: Goodrive270 series VFD for fan and pump
Rated power
ĸ
Power range
160: 160kW
Voltage class Ĺ Voltage class
4: AC 3PH 380V±480V
Rated voltage: 380V
Management
number
ĺ Optional
Default: Empty
L1: with built-in DC reactor, applicable to 30±355kW
models.
L2: with output AC reactor, applicable to 220kW and
higher models.
L3: with built-in DC reactor and output AC reactor,
applicable to 220kW and higher models.
Note: DC reactors are standard parts for 400±
500kW models.
