INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-66-
Function
code
Name Description Default
7: Ethernet communication
8: Reserved
9: EtherCAT/PROFINET communication
10: Programmable expansion card
11±17: Reserved
18: Keypad (for small power models)
Note: For setting sources 1±4, 100%
corresponds to triple the motor rated current.
P03.19
Setting source of
braking torque
upper limit
0: Keypad (P03.21)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet communication
7: Ethernet communication
8: Reserved
9: EtherCAT/PROFINET communication
10: Programmable expansion card
11±17: Reserved
18: Keypad (for small power models)
Note: For setting sources 1±4, 100%
corresponds to triple the motor rated current.
0
P03.20
Electromotive
torque upper limit
set through
keypad
0.0±300.0% (of the motor rated current) 180.0%
P03.21
Braking torque
upper limit set
through keypad
0.0±300.0% (of the motor rated current) 180.0%
P17.09 Output torque -250.0±250.0% 0.0%
P17.15
Torque reference
value
-300.0±300.0% (of the motor rated current) 20.0%
5.5.6 Motor parameters
 Check the safety conditions surrounding the motor and load machineries before
autotuning as physical injury may occur due to sudden start of motor during
autotuning.
