Goodrive270 series VFD for fan and pump Basic operation guidelines
-47-
Name Description Default
P05.01±
P05.06
multifunction digital
input terminals (S1±
36: Switch the running command channel to keypad
37: Switch the running command channel to terminal
38: Switch the running command channel to
P07.01 Parameter copy
Used to set the parameter copy mode.
0: No operation
1: Upload parameters from the local address to the
keypad
2: Download parameters (including motor
parameters) from the keypad to the local address
3: Download parameters (excluding group P02.00)
from the keypad to the local address
4: Download parameters (only including group P02)
from the keypad to the local address
Note: After any operation among 1±4 is
completed, the parameter restores to 0. The
upload and download functions are not
0
P07.02
Function of
QUICK/JOG
Range: 0x00±0x27
Ones place: Function of QUICK/JOG
0: No function
1: Jog
2: Reserved
3: Switch between forward and reverse rotating
4: Clear the UP/DOWN setting
5: Coast to stop
6: Switch command channels in sequence
7: Reserved
0x01
5.5.3 Vector control
AMs feature high order, nonlinearity, strong coupling and multi-variables, which increase difficulty to
control AMs during actual application. The vector control technology solves this situation as follows:
measures and controls the stator current vector of the AM, and then decomposes the stator current
vector into exciting current (current component that generates internal magnet field) and torque
current (current component that generates torque) based on field orientation principle, and therefore
controls the amplitude values and phase positions of the two components (namely, controls the stator
current vector of the AM) to realize decoupled control on exciting current and torque current, thus
achieving high-performance speed regulation of the AM.
