INVT GD270-030-4 - P16 Group Communication Expansion Card 2 Functions; P17 Group Status Viewing

Goodrive270 series VFD for fan and pump Function parameter list
-207-
P16 group²Communication expansion card 2 functions
Function
code
Name Description Default
Modify
P16.00±
P16.23
See the communication
expansion card operation manual for details.
P16.24
Time to identify
expansion card in
card slot 1
0.0
±600.0s
The value 0.0 indicates that identification fault
will not be detected.
0.0s ƻ
P16.25
Time to identify
expansion card in
card slot 2
0.0
±600.0s
T
he value 0.0 indicates that identification fault
will not be detected.
0.0s ƻ
P16.26 Reserved
0.0
±600.0s
The value 0.0 indicates that identification fault
will not be detected.
0.0s ƻ
P16.27
Communication
timeout period of
card at slot 1
0.0
±600.0s
The v
alue 0.0 indicates offline fault will not be
detected.
0.0s ƻ
P16.28
Communication
timeout period of
card at slot 2
0.0
±600.0s
The value 0.0 indicates offline fault will not be
detected.
0.0s ƻ
P16.29
Reserved
P16.30±
P16.69
See the communication expa
nsion card operation manual for details.
P17 group²Status viewing
Function
code
Name Description Default
Modify
P17.00 Set frequency
Displays the present set frequency of the VFD.
Range: 0.00Hz±P00.03
50.00Hz ƽ
P17.01 Output frequency
Displays the present output frequency of the
VFD.
Range: 0.00Hz±P00.03
0.00Hz ƽ
P17.02
Ramp reference
frequency
Displays the present ramp reference frequency
of the VFD.
Range: 0.00Hz±P00.03
0.00Hz ƽ
P17.03 Output voltage
Displays the present output voltage of the VFD.
Range: 0±1200V
0V ƽ
P17.04 Output current
Displays the valid value of current output current
of the VFD.
Range: 0.0±5000.0A
0.0A ƽ
