INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-103-
Function code
Name
Description
Default
P10.09 Run time of step 3 0.0±6553.5s (min) 0.0s
P10.10 Multi-step speed 4 -100.0±100.0% 0.0%
P10.11 Run time of step 4 0.0±6553.5s (min) 0.0s
P10.12 Multi-step speed 5 -100.0±100.0% 0.0%
P10.13 Run time of step 5 0.0±6553.5s (min) 0.0s
P10.14 Multi-step speed 6 -100.0±100.0% 0.0%
P10.15 Run time of step 6 0.0±6553.5s (min) 0.0s
P10.16 Multi-step speed 7 -100.0±100.0% 0.0%
P10.17 Run time of step 7 0.0±6553.5s (min) 0.0s
P10.18 Multi-step speed 8 -100.0±100.0% 0.0%
P10.19 Run time of step 8 0.0±6553.5s (min) 0.0s
P10.20 Multi-step speed 9 -100.0±100.0% 0.0%
P10.21 Run time of step 9 0.0±6553.5s (min) 0.0s
P10.22 Multi-step speed 10 -100.0±100.0% 0.0%
P10.23 Run time of step 10 0.0±6553.5s (min) 0.0s
P10.24 Multi-step speed 11 -100.0±100.0% 0.0%
P10.25 Run time of step 11 0.0±6553.5s (min) 0.0s
P10.26 Multi-step speed 12 -100.0±100.0% 0.0%
P10.27 Run time of step 12 0.0±6553.5s (min) 0.0s
P10.28 Multi-step speed 13 -100.0±100.0% 0.0%
P10.29 Run time of step 13 0.0±6553.5s (min) 0.0s
P10.30 Multi-step speed 14 -100.0±100.0% 0.0%
P10.31 Run time of step 14 0.0±6553.5s (min) 0.0s
P10.32 Multi-step speed 15 -100.0±100.0% 0.0%
P10.33 Run time of step 15 0.0±6553.5s (min) 0.0s
P10.34
ACC/DEC time of steps 0±7
of simple PLC
0x0000±0XFFFF 0000
P10.35
ACC/DEC time of steps 8±
15
of simple PLC
0x0000±0XFFFF 0000
P17.27 Present step of simple PLC
Used to display the present
step of the simple PLC function.
0
5.5.15 PID control
PID control, a common mode for process control, is mainly used to adjust the VFD output frequency
