INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-65-
Function
code
Name Description Default
9: Reserved
10: EtherCAT/PROFINET communication
11: Programmable expansion card
12: Reserved
Note: For setting sources 1±5, 100%
corresponds to the max. frequency.
P03.15
Setting source of
reverse rotation
upper-limit
frequency in
torque control
0: Keypad (P03.17)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: PROFIBUS/CANopen/DeviceNet communication
8: Ethernet communication
9: Reserved
10: EtherCAT/PROFINET communication
11: Programmable expansion card
12: Reserved
Note: For setting sources 1±5, 100%
corresponds to the max. frequency.
0
P03.16
Forward rotation
upper-limit
frequency set
through keypad in
torque control
0.00Hz±P00.03(Max. output frequency) 50.00 Hz
P03.17
Reverse rotation
upper-limit
frequency set
through keypad in
torque control
0.00Hz±P00.03(Max. output frequency) 50.00 Hz
P03.18
Setting source of
electromotive
torque upper limit
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet communication
0
