INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-85-
Related parameter list:
Function
code
Name Description Default
P06.00
Reserved
Reserved
P06.14
AO1 output
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Rotational speed
4: Output current (relative to the VFD)
5: Output current (relative to the motor)
6: Output voltage
7: Output power
8: Set torque
9: Output torque
10: AI1 input
11: AI2 input
12: AI3 input
13: High-speed pulse HDIA input
14: Value 1 set through Modbus
communication
15: Value 2 set through Modbus
communication
16: Value 1 set through
PROFIBUS/CANopen/DeviceNet
communication
17: Value 2 set through
PROFIBUS/CANopen/DeviceNet
communication
18: Value 1 set through Ethernet
communication
19: Value 2 set through Ethernet
communication
20: Reserved
21: Value 1 set through
EtherCAT/PROFINET/EthernetIP
22: Torque current (bipolar, 100%
corresponding to 10V)
23: Exciting current (100%
corresponding to 10V)
0
P06.15
AO0 output
0
P06.16 Reserved 0
