INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-84-
Setting
Function
Description
16
Value 1 set through
PROFIBUS/CANopen/DeviceNet
communication
0±1000
17
Value 2 set through
PROFIBUS/CANopen/DeviceNet
communication
0±1000
18
Value 1 set through Ethernet
communication
0±1000
19
Value 2 set through Ethernet
communication
0±1000
20
High-speed pulse HDIA input
0.00±50.00kHz
21
Value 1 set through
EtherCAT/PROFINET
communication
0±1000. A negative value corresponds to
0.0% by default.
22 Torque current (bipolar)
0±Triple the motor rated current. A negative
value corresponds to 0.0% by default.
23 Exciting current
0±Triple the motor rated current. A negative
value corresponds to 0.0% by default.
24 Set frequency (bipolar)
0±Max. output frequency. A negative value
corresponds to 0.0% by default.
25 Ramp reference frequency (bipolar)
0±Max. output frequency. A negative value
corresponds to 0.0% by default.
26 Rotational speed (bipolar)
0±Synchronous rotation speed
corresponding to max. output frequency. A
negative value corresponds to 0.0% by
default.
27
Value 2 set through
EtherCAT/PROFINET
communication
0±1000
30 Rotational speed
0±Twice the motor rated synchronous
rotation speed
31 Output torque (bipolar)
0±Twice the motor rated torque. A negative
value corresponds to 0.0% by default.
32±47
Reserved
