INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-182-
Function
code
Name Description Default
Modify
0: Keypad (
P09.01)
1: AI1
2: AI2
3: AI3
4: High
-speed pulse HDIA
5: Multi
-step running
6: Modbus communication
7:
PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
9: Reserved
10: EtherCAT/PROFINET communication
11: Programmable expansion card
12: Reserve
d
The set target of process PID is a relative value,
for which 100% equals 100% of the feedback
signal of the controlled system.
The system always performs calculation by using
a relative value (0±100.0%).
P09.01
PID reference preset
through keypad
Th
e function code is mandatory when P09.00
=0.
The base value of The function code is the
feedback of the system.
Setting range: -100.0%±100.0%
0.0% ƻ
P09.02
PID feedback source
Used to select PID feedback channel.
0: AI1
1: AI2
2:
AI3
3: High
-speed pulse HDIA
4: Modbus communication
5:
PROFIBUS/CANopen/DeviceNet
communication
6: Ethernet communication
7: Reserved
8: EtherCAT/PROFINET communication
9: Programmable expansion card
10: Reserved
Note: The reference channel and feedback
0 ƻ
