INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Function parameter list
-214-
Function
code
Name Description Default
Modify
P23.01
setting range: 0.000±10.000s
P23.02
setting range: 0.00Hz±P23.05
P23.03
setting range: 0.0±200.0
P23.04
setting range: 0.000±10.000s
P23.05
setting range: P23.02±P00.03 (Max.
output frequency)
P23.06
Speed-loop output
filter
0
±8 (corresponding to 0±2
8
/10ms) 0 ƻ
P23.07
Electromotive slip
compensation
coefficient of vector
control
Slip compensation coefficient is used to adjust
the slip frequency of the vector control and
improve the speed control accuracy
of the
system. Adjusting the parameter properly can
control the speed steady
-state error.
Setting range: 50
±200%
100% ƻ
P23.08
Braking slip
compensation
coefficient of vector
control
100% ƻ
P23.09
Current-loop
proportional
coefficient P
Note:

The two function codes impact the dynamic
response speed and control accuracy of the
system. Generally, you do not need to modify
the two function codes.

Applicable to SVC mode 0 (P00.00=0)

The values of the two function codes are
updated automatically after SM parameter
autotuning is completed.
Setting range: 0±65535
1000 ƻ
P23.10
Current
-
loop integral
coefficient I
1000 ƻ
P23.11
Speed-loop
differential gain
0.00
±10.00s 0.00s ƻ
P23.12
High-frequency
current-loop
proportional
coefficient
In the closed
-loop vector control mode
(
P00.00=3), when th
e frequency is lower than the
current
-loop high-frequency switching threshold
(
P23.14), the current-loop PI parameters are
P23.09
and P23.10; and when the frequency is
higher tha
n the current-loop high-frequency
switching threshold, the current
-loop PI
parameters are
P23.12 and P23.13.
P23.12
setting range: 0±65535
P23.13 setting range: 0±65535
1000 ƻ
P23.13
High-frequency
current-
loop integral
coefficient
1000 ƻ
P23.14
Current-loop
high-frequency
100.0% ƻ
