INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Expansion card
-290-
Field
Description
Naming example
Remarks
card
18: Reserved 1
19: Reserved 2
Product code
(I/O card)
01: Multiple-function I/O card
02: Multiple-function I/O card (with
the temperature detection function)
03: Reserved
Product code
(IC card)
01: GPRS card
02: 4G card
03: Reserved
Ļ Working power
00: Passive
05: 5V
12: 12-15V
24: 24V
(Empty by default)
ļ
Version
description
Used to distinguish the
hardware/structure.
A: Standard version
B: B version
(Empty by default)
The following table describes expansion cards that the VFD supports. The expansion cards are
optional and need to be purchased separately.
Name
Model
Specifications
IO expansion card EC-IO501-00
ƔGLJLWDOLQSXWV
ƔGLJLWDORXWSXW
ƔDQDORJLQSXW
ƔDQDORJRXWSXW
ƔUHOD\RXWSXWVGRXEOH-contact output, and 1
single-contact output
PROFIBUS-DP
communication
card
EC-TX503 Ɣ6XSSRUWLQJWKHPROFIBUS-DP protocol
Ethernet
communication
card
EC-TX504
Ɣ6XSSRUWLQJ(WKHUQHWFRPPXQLFDWLRQZLWK,197VLQWHUQDO
protocol.
Ɣ&DQEHXVHGLQFRPELQDWLRQZLWK,197VXSSHr computer
monitoring software INVT Workshop.
CANopen
EC-TX505
Ɣ%DVHGRQWKH&$1$SK\VLFDOOD\HU

INVT GD270-030-4 Specifications

General

Brand	INVT
Model	GD270-030-4
Category	Water Pump
Language	English
