INVT GD270-030-4 User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-79-
Function
code
Name Description Default
frequency command
1: A frequency command
P00.09
Combination mode of setting
source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max(A, B)
5: Min(A, B)
0
P05.01±
P05.06
Function selection of
multifunction digital input
terminals (S1±S4, and HDIA)
10: Increase frequency setting (UP)
11: Decrease frequency setting (DOWN)
12: Clear the frequency increase/decrease
setting
13: Switch between A setting and B setting
14: Switch between combination setting
and A setting
15: Switch between combination setting
and B setting
P08.42 Keypad digital control setting
0x0000±0x1223
LED ones place:
0: Both the ġ / Ģ
key and digital
potentiometer can be used for the control.
1: Only the ġ/Ģ
key can be used for the
control.
2: Only the digital potentiometer can be
used for the control.
3: Neither the ġ/ Ģ
key nor the digital
potentiometer can be used for the control.
Tens place: Frequency control selection
0: Valid only when P00.06=0 or P00.07=0
1: Valid for all frequency setting methods
2: Invalid for multi-
step speed running
when multi-
step speed running has the
priority
LED hundreds place: Action selection for
stop
0: Setting is valid.
1: Valid during running, cleared after stop
2: Valid during running, cleared after a stop
command is received
0x0000
