INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-110-
Function
code
Name
Description
Default
Modify
P17.30
Phase
compensati
on quantity
of SM
Displays the phase compensation quantity of
synchronous motor.
Range: -180.0–180.0
0.0
●
P17.31
High-freque
ncy
superpositio
n
current of
SM
Displays the high-frequency superposition
current of synchronous motor.
Range: 0.0–200.0% (of the rated motor current)
0.0
●
P17.32
Flux linkage
Displays the flux linkage of the motor.
Range: 0.0–200.0%
0.0%
●
P17.33
Exciting
current
reference
Displays the exciting current reference value
under vector control mode.
Range: -3000.0–3000.0A
0.0A
●
P17.34
Torque
current
reference
Displays torque current reference value under
vector control mode.
Range: -3000.0–3000.0A
0.0A
●
P17.35
AC
incoming
current
Displays the valid value of incoming current on
AC side.
Range: 0.0–5000.0A
0.0A
●
P17.36
Output
torque
Display output torque value, during forward
running, positive value is motoring state,
negative value is generating state; during
reverse running, positive value is generating
state, negative value is motoring state.
Range: -3000.0Nm–3000.0Nm
0.0Nm
●
P17.37
Motor
overload
count value
0–100 (OL1 fault is reported when the count
value reaches 100)
0
●
P17.38
PID output
value
Displays the output value of PID control.
-100.00–100.00%
0.00%
●
P17.39
Function
parameter
in
parameter
download
error
0.00–99.99
0.00
●
