INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-109-
Function
code
Name
Description
Default
Modify
P17.17
Reserved
P17.18
Counting
value
Displays the current counting number of the
VFD.
Range: 0–65535
0
●
P17.19
AI1 input
voltage
Displays input signal of AI1.
Range: 0.00–10.00V
0.00V
●
P17.20
AI2 input
voltage
Displays input signal of AI2.
Range: 0.00–10.00V
0.00V
●
P17.21
AI3 input
voltage
Displays input signal of AI3.
Range: -10.00–10.00V
0.00V
●
P17.22
HDI input
frequency
Displays input frequency of HDI.
Range: 0.000–50.000kHz
0.000kHz
●
P17.23
PID
reference
value
Displays PID reference value.
Range: -100.0–100.0%
0.0%
●
P17.24
PID
feedback
value
Displays PID feedback value.
Range: -100.0–100.0%
0.0%
●
P17.25
Motor
power
factor
Displays the power factor of current motor.
Range: -1.00–1.00
0.00
●
P17.26
Current
running
time
Displays current running time of the VFD.
Range: 0–65535min
0min
●
P17.27
Simple PLC
and current
step
number
of multi-step
speed
Displays simple PLC and current step number of
multi-step speed
Range: 0–15
0
●
P17.28
ASR
controller
output
Displays the speed loop ASR controller output
value under vector control mode, relative to the
percentage of rated torque of the motor.
Range: -300.0%–+300.0% (of the rated motor
current)
0.0%
●
P17.29
Magnetic
pole angle
of SM
Displays the magnetic pole angle of synchronous
motor.
Range: 0.0–360.0
0.0
●
