INVT Goodrive30 VFD Series

Goodrive30 Series VFD Dimension drawings
-152-
Model
W1
W2
W3
H1
H2
D1
D2
Installation
hole
Weight
(kg)
GD30-1R5G-2
146.0
131.0
—
256.0
243.5
167.0
84.5
6
3.1
GD30-2R2G-2
146.0
131.0
—
256.0
243.5
167.0
84.5
6
3.1
GD30-004G-2
146.0
131.0
—
256.0
243.5
167.0
84.5
6
3.1
GD30-5R5G-2
170.0
151.0
—
320.0
303.5
196.3
113.0
6
5.58
GD30-7R5G-2
170.0
151.0
—
320.0
303.5
196.3
113.0
6
5.83
GD30-004G-4
146.0
131.0
—
256.0
243.5
167.0
84.5
6
3.1
GD30-5R5G-4
146.0
131.0
—
256.0
243.5
167.0
84.5
6
3.1
GD30-7R5G-4
170.0
151.0
—
320.0
303.5
196.3
113.0
6
5.58
GD30-011G-4
170.0
151.0
—
320.0
303.5
196.3
113.0
6
5.58
GD30-015G-4
170.0
151.0
—
320.0
303.5
196.3
113.0
6
5.83
GD30-018G-4
200.0
185.0
—
340.6
328.6
184.3
104.5
6
9
GD30-022G-4
200.0
185.0
—
340.6
328.6
184.3
104.5
6
9
GD30-030G-4
250.0
230.0
—
400.0
380.0
202.0
123.5
6
15.5
GD30-037G-4
250.0
230.0
—
400.0
380.0
202.0
123.5
6
15.5
GD30-045G-4
282.0
160.0
226.0
560.0
542.0
238.0
138.0
9
25
GD30-055G-4
282.0
160.0
226.0
560.0
542.0
238.0
138.0
9
25
GD30-075G-4
282.0
160.0
226.0
560.0
542.0
238.0
138.0
9
25
GD30-090G-4
338.0
200.0
—
554.0
535.0
329.2
—
9.5
45
GD30-110G-4
338.0
200.0
—
554.0
535.0
329.2
—
9.5
45
Installation hole
Figure B-9 Flange mounting of VFDs of 3PH 380V (4–75kW) and 3PH 220V (1.5–7.5kW)
