INVT Goodrive30 VFD Series

Goodrive30 Series VFD Dimension drawings
-153-
W1
W3
H1
D1
D2
H2
H3
H4
W2
W3
W4
Figure B-10 Flange mounting of VFDs of 3PH 380V (90–110kW)
Model
W1
W2
W3
W4 H1 H2 H3 H4 D1 D2
Installati
on hole
Screw
Weigh
t
(kg)
GD30-1R5G-
2
170.2
131
150
9.5 292 276 260 6 167 84.5 6 M5 3.1
GD30-2R2G-
2
170.2
131
150
9.5 292 276 260 6 167 84.5 6 M5 3.1
GD30-004G-
2
170.2
131
150
9.5 292 276 260 6 167 84.5 6 M5 3.1
GD30-5R5G-
2
191.2
151
174
11.5 370 351 324 12 196.3 113 6 M5 5.58
GD30-7R5G-
2
191.2
151
174
11.5 370 351 324 12 196.3 113 6 M5 5.83
GD30-004G-
4
170.2
131
150
9.5 292 276 260 6 167 84.5 6 M5 3.1
GD30-5R5G-
4
170.2
131
150
9.5 292 276 260 6 167 84.5 6 M5 3.1
GD30-7R5G-
4
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
5.58
GD30-011G-
4
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
5.58
GD30-015G-
4
191.2
151
174
11.5
370
351
324
12
196.3
113
6
M5
5.83
GD30-018G-
4
266
250
224
13
371
250
350.
6
20.3
184.6
104
6
M5
9
GD30-022G-
266
250
224
13
371
250
350.
20.3
184.6
104
6
M5
9
