INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Keypad operation procedure
-26-
Serial
No.
Name
Description
1
Status
indicator
RUN/TUNE
VFD running status indicator.
LED off: The VFD is stopped.
LED blinking: The VFD is autotuning parameters.
LED on: The VFD is running.
FWD/REV
Forward or reverse running indicator.
LED off: The VFD is running forward.
LED on: The VFD is running reversely.
LOCAL/REMOT
Indicates whether the VFD is controlled through the
keypad, terminals, or remote communication.
LED off: The VFD is controlled through the keypad.
LED blinking: The VFD is controlled through
terminals.
LED on: The VFD is controlled through remote
communication.
TRIP
Fault indicator
LED on: in fault state
LED off: in normal state
LED blinking: in pre-alarm state
2
Unit
indicator
Unit displayed currently.
Hz
Frequency unit
RPM
Rotating speed unit
A
Current unit
％
Percentage
V
Voltage unit
