INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-44-
Function
code
Name
Description
Default
Modify
function. Otherwise, serious result may follow.
P01.19
Action
selected
when
running
frequency
less than
frequency
lower limit
(valid when
frequency
lower limit
greater than
0)
The function code determines the running state
of the VFD when the set frequency is lower than
the lower-limit one.
0: Run at the frequency lower limit
1: Stop
2: Sleep
The VFD coasts to stop when the set frequency
is lower than the lower-limit one. If the set
frequency exceeds the lower limit one again and
it lasts for the time set by P01.20, the VFD
resumes the running state automatically.
0
◎
P01.20
Wake-up-fr
om-sleep
delay
The function code determines the
wake-up-from-sleep delay time. When the
running frequency of the VFD is lower than the
lower limit, the VFD becomes standby.
When the set frequency exceeds the lower limit
one again and it lasts for the time set by P01.20,
the VFD runs automatically.
Set frequency curve:
Running frequency curve:
Run Sleep
t2
t1
Run
Frequency
lower limit f0
Frequency f
Time t
Coast to
stop
t1 < P01.20, the VFD does not run
t1+t2 ≥P01.20, the VFD runs
Setting range: 0.0–3600.0s (valid when
P01.19=2)
0.0s
○
P01.21
Restart
after
power-off
The function code indicates whether the VFD
automatically runs after re-power on.
0: Disable
1: Enable. If the restart condition is met, the VFD
will run automatically after waiting the time
defined by P01.22.
0
○
