INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-46-
Function
code
Name
Description
Default
Modify
P02.04
Rated
voltage of
AM 1
0–1200V
asynchronous motor.
The Goodrive30 series VFD
provides the parameter
autotuning function. Whether
parameter autotuning can be
performed properly depends
on the settings of the motor
nameplate parameters.
In addition, you need to
configure a motor based on
the standard motor
configuration of the VFD. If
the power of the motor is
greatly different from that of
the standard motor
configuration, the control
performance of the VFD
degrades significantly.
Note: Resetting the rated
power of the motor (P02.01)
can initialize the parameters
of P02.02 to P02.10.
Model
depended
◎
P02.05
Rated
current of
AM 1
0.8–6000.0A
Model
depended
◎
P02.06
Stator
resistor of
AM 1
0.001–65.535Ω
After motor parameter
autotuning is properly
performed, the values of
P02.06 to P02.10 are
automatically updated.
These parameters are the
reference parameters for
high-performance vector
control, directly affecting the
control performance.
Note: Do not modify these
parameters unless it is
necessary.
Model
depended
○
P02.07
Rotor
resistor of
AM 1
0.001–65.535Ω
Model
depended
○
P02.08
Leakage
inductance
of AM 1
0.1–6553.5mH
Model
depended
○
P02.09
Mutual
inductance
of AM 1
0.1–6553.5mH
Model
depended
○
P02.10
Non-load
current of
AM 1
0.1–6553.5A
Model
depended
○
