INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-47-
Function
code
Name
Description
Default
Modify
P02.11
Magnetic
saturation
coefficient 1
of iron core
of AM 1
0.0–100.0%
80.0%
○
P02.12
Magnetic
saturation
coefficient 2
of iron core
of AM 1
0.0–100.0%
68.0%
○
P02.13
Magnetic
saturation
coefficient 3
of iron core
of AM 1
0.0–100.0%
57.0%
○
P02.14
Magnetic
saturation
coefficient 4
of iron core
of AM 1
0.0–100.0%
40.0%
○
P02.15
Rated
power of
SM 1
0.1–3000.0kW
The function code is used to
set parameters of the
controlled synchronous
motor.
To ensure the control
performance, set
P02.15–P02.19 correctly
according to the information
on the nameplate of the
synchronous motor.
The Goodrive30 series VFD
provides the parameter
autotuning function. Whether
parameter autotuning can be
performed properly depends
on the settings of the motor
nameplate parameters.
In addition, you need to
Model
depended
◎
P02.16
Rated
frequency
of SM 1
0.01Hz–P00.03
(Max. output
frequency)
50.00Hz
◎
P02.17
Number of
pole pairs of
SM 1
1–50
2
◎
P02.18
Rated
voltage of
SM 1
0–1200V
Model
depended
◎
P02.19
Rated
current of
SM 1
0.8–6000.0A
Model
depended
◎
