INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-48-
Function
code
Name
Description
Default
Modify
configure a motor based on
the standard motor
configuration of the VFD. If
the power of the motor is
greatly different from that of
the standard motor
configuration, the control
performance of the VFD
degrades significantly.
Note: Resetting the rated
power of the motor (P02.15)
can initialize the parameters
of P02.16 to P02.19.
P02.20
Stator
resistance
of SM 1
0.001–65.535Ω
After motor parameter
autotuning is properly
performed, the values of
P02.20 to P02.22 are
automatically updated.
These parameters are the
reference parameters for
high-performance vector
control, directly affecting the
control performance.
When P00.15=1 (rotary
autotuning), the set value of
P02.23 may be automatically
updated by autotuning, In
this case, there is no need to
change the value of P02.23.
When P00.15=2 (static
autotuning), the set value of
P02.23 cannot be updated by
autotuning. In this case, you
need to calculate and
manually change the value of
P02.23.
Model
depended
○
P02.21
Direct-axis
inductance
of SM 1
0.01–655.35mH
Model
depended
○
P02.22
Quadrature-
axis
inductance
of SM 1
0.01–655.35mH
Model
depended
○
P02.23
Counter-em
f constant of
SM 1
When P00.15=2,
the set value of
P02.23 cannot be
updated by
autotuning, please
count according to
the following
method.
The counter-emf
constant can be
counted according
to the parameters
on the nameplate
of the motor. There
are three ways to
300
○
