INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-53-
Function
code
Name
Description
Default
Modify
P03.11
Torque
setting
method
The function code is used to enable the torque
control mode, and set the torque setting method.
0: Invalid
1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
5: Pulse frequency HDI
6: Multi-step torque
7: Modbus communication
8–10: Reserved
Note: For setting methods 2–7, 100%
corresponds to three times the motor rated
current.
0
○
P03.12
Torque set
through
keypad
Setting range: -300.0%–300.0% (of the rated
motor current)
50.0%
○
P03.13
Torque
reference
filter time
0.000–10.000s
0.010s
○
P03.14
Setting
source of
forward
rotation
upper-limit
frequency in
torque
control
0: Keypad (P03.16 sets the value when
P03.14=1; P03.17 sets the value when
P03.15=1)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI
5: Multi-step setting
6: Modbus communication
7–9: Reserved
Note: For setting methods 1–6, 100%
corresponds to the maximum frequency.
0
○
P03.15
Setting
source of
reverse
rotation
upper-limit
frequency in
torque
control
0
○
P03.16
Forward
rotation
The function codes are used to set the frequency
upper limits. 100% corresponds to the max.
50.00 Hz
○
