INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-54-
Function
code
Name
Description
Default
Modify
upper-limit
frequency
set through
keypad in
torque
control
frequency. P03.16 sets the value when
P03.14=1; P03.17 sets the value when
P03.15=1.
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
P03.17
Reverse
rotation
upper-limit
frequency
set through
keypad in
torque
control
50.00 Hz
○
P03.18
Setting
source of
electromotiv
e torque
upper limit
This function codes are used to select the setting
sources of electromotive and braking torque
upper limits.
0: Keypad (P03.20 sets P03.18 and P03.21 sets
P03.19)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI
5: Modbus communication
6–8: Reserved
Note: For setting methods 1–5, 100%
corresponds to three times the motor rated
current.
0
○
P03.19
Setting
source of
braking
torque
upper limit
0
○
P03.20
Electromoti
ve torque
upper limit
set through
keypad
The function codes are used to set torque limits.
Setting range: 0.0–300.0% (of the motor rated
current)
180.0%
○
P03.21
Braking
torque
upper limit
set through
keypad
180.0%
○
