INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-76-
Function
code
Name
Description
Default
Modify
P07.05
Selection 1
of
parameters
displayed in
running
state
0x0000–0xFFFF
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz blinks)
BIT2: Bus voltage (V on)
BIT3: Output voltage (V on)
BIT4: Output current (A on)
BIT5: Running rotating speed (rpm on)
BIT6: Output power (% on)
BIT7: Output torque (% on)
BIT8: PID reference value (% blinks)
BIT9: PID feedback value (% on)
BIT10: Input terminal state
BIT11: Output terminal state
BIT12: Torque setting value (% on)
BIT13: Pulse counting value
BIT14: Length value
BIT15: PLC and current step of multi-step speed
0x03FF
○
P07.06
Selection 2
of
parameters
displayed in
running
state
0x0000–0xFFFF
BIT0: AI1 (V on)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: High-speed pulse HDI frequency
BIT4: Motor overload percentage (% on)
BIT5: VFD overload percentage (% on)
BIT6: Ramp frequency reference value (Hz on)
BIT7: Linear speed
BIT8: AC incoming current (A on)
BIT9: Upper limit of frequency (Hz on)
BIT10–15: Reserved
0x0000
○
P07.07
Selection of
parameters
displayed in
stopping
state
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency blinks
slowly)
BIT1: Bus voltage (V on)
BIT2: Input terminal state
BIT3: Output terminal state
BIT4: PID reference value (% blinks)
BIT5: PID feedback value (% on)
BIT6: Torque setting value (% on)
BIT7: AI1 (V on)
0x00FF
○
