INVT Goodrive30 VFD Series User Manual

Goodrive30 Series VFD Function parameter list
-77-
Function
code
Name
Description
Default
Modify
BIT8: AI2 (V on)
BIT9: AI3 (V on)
BIT10: High-speed pulse HDI frequency
BIT11: PLC and current step of multi-step speed
BIT12: Pulse counting value
BIT13: Length value
BIT14: Upper limit of frequency (Hz on)
BIT15: Reserved
P07.08
Frequency
display
coefficient
0.01–10.00
Displayed frequency = Running frequency *
P07.08
1.00
○
P07.09
Rotational
speed
display
coefficient
0.1–999.9%
Mechanical rotation speed =120 * (Displayed
running frequency) × P07.09/(Number of motor
pole pairs)
100.0%
○
P07.10
Linear
speed
display
coefficient
0.1–999.9%
Linear speed = (Mechanical rotation speed) ×
P07.10
1.0%
○
P07.11
Temperatur
e of rectifier
bridge
module
-20.0–120.0℃
●
P07.12
Temperatur
e of inverter
module
-20.0–120.0℃
●
P07.13
Software
version of
control
board
1.00–655.35
●
P07.14
Accumulate
d running
time
0–65535h
●
P07.15
High bit of
power
consumptio
n of the
VFD
The function codes are used to display the power
consumption of the VFD.
VFD power consumption =P07.15*1000+P07.16
Setting range of P07.15: 0–65535kWh (*1000)
Setting range of P07.16: 0.0–999.9kWh
●
