Appendix-2
Appendix
A-1. SPECIFICATIONS
Model Name IP-AI
Weigh Unit Weighing Capacity *1 0 - 3 kg x 0.001 kg / 3 - 6 kg x 0.002 kg
0 - 6 kg x 0,002 kg / 6 - 15 kg x 0.005 kg
0 - 15 lb x 0.005 lb /15 - 30 lb x 0.01 lb
Weighing Accuracy 1/3000 (Multi Interval)
Controller Unit Dsplay Console Backlit 12.1-inch color LCD touch-panel (SVGA: 800×600dots)
Tactile Keys 19Keys
Printer Print Head 3inch direct thermal (960dots), 12dots/mm, 80mm wide head
Printing Speed 150mm/sec
Print Area Width: Up to 78mm (3.1inch)
Label Size Width: 20 - 80mm (0.8 - 3.1inch)
Height: 20 - 150mm ( 0.8 - 5.9 inch)
Number of Printer 1
Label Roll Size
- Inner Core Diameter φ76mm (3.0inch)
- Outer Core Diameter φ224mm (9.0inch) or less
Label Storage Capacity 5,000 labels/roll (at 42mm (H) and 2.5mm gap)
Interface Ethernet RJ45 x 1, 1000B-T
Wireless 802.11 b/g *2
USB x 4, USB 2.0
Scanner via USB interface
Others Power Supply Single phase, AC 100 - 240V (+10%/-10%), 50/60Hz
Power Comsumption Standby: 40W or less, Maximum: 200W *3
Memory Capacity 2GB
Dimensions Main Body: 302 × 380 × 673
mm
(Width x Depth x Height)
Weigh Unit: 300 × 270 × 88mm (Width x Depth x Height)
Weight Main Body: Approx. 19kg
Weigh Unit: Approx. 6kg
Operation Environment Temperature:0
- 40
, Humidity:20% - 85% (no condensation)
Standards UL, UL, EU/NTEP type approval
*1: Factory tted option
*2: Optional
*3: Power consumption varies dependent on site conditions and machine setup.
Speci cations subject to change without notice.
