5.1.10.3 SOD (Stationary Object Detection)
Stationary Object Detection function detects the objects left over or lost in the pre-defined region
such as the baggage, purse, dangerous materials, etc., and a series of actions can be taken when
the alarm is triggered.
Channel: to select the channel you want to configure
Switch: to enable or disable the SOD function
Sensitivity: The sensitivity level is from 1 to 4, with a default value of 2. Higher sensitivity will be
easier to trigger the detection.
Scene: Scene setting includes Indoor and Outdoor. Please choose the scene to match with the
place your camera installed.
Click on the “Alarm” button on the bottom right hand of the screen for the menu (below) to appear
Buzzer: Disable or to active the buzzer to emit an alarm tone in 10, 20, 40 or 60 seconds when the
detection is triggered
Record: Click icon and choose which channel(s) you want to record when the PID event is
triggered.
