Specifications
Static Dimensions
197 197
9811-3400-4
Table 26.
Note: Dimensions based on a machine equipped with the
standard 2.4m
3
shovel and 20.5R25 tyres.
HT ZX
mm (ft-in) mm (ft-in)
A Overall length (includes standard shovel) 6926 (22-9) 7169 (23-6)
B Axle to pivot pin 1143 (3-9) 1143 (3-9)
C Wheelbase 3000 (9-10) 3000 (9-10)
D Axle to counterweight face 1816 (5-11) 1816 (5-11)
E Minimum ground clearance 459 (1-6) 459 (1-6)
F Height over exhaust 3192 (10-6) 3192 (10-6)
G Width over cab 1400 (4-7) 1400 (4-7)
H Width over tyres 2597 (8-6) 2597 (8-6)
H1 Wheel track 2070 (6-9) 2070 (6-9)
J Height over cab 3335 (10-11) 3335 (10-11)
K Pivot pin height (maximum) 3996 (13-1) 3996 (13-1)
L Maximum operating height 5305 (17-5) 5305 (17-5)
M Shovel dump height 2974 (9-8) 2965 (9-9)
Degrees Degrees
N Axle oscillation 10.5 10.5
P Shovel dump angle at full height 50 47
Q Shovel crowd angle at full height 58 58
Articulation angle 40 40
kg (lb) kg (lb)
Unladen weight 14503 (31974) 14922 (32900)
