4 – 4
4
Measurement between Two Optional Points
.
...
……Measurement between Two Optional Points ……………………
The procedures of measuring the range and bearing between two optional points by using EBL2
will be described below.
1 Press to select EBL2 display and operation.
The “EBL2” indication at the lower right of the radar display will be selected and the EBL2 will
appear as a dotted-line on the PPI display.
2 Press .
The Main Menu will appear.
3 Press .
“OFFSET” in “6.EBL2” will be set.
4 Using the trackball, move the starting point of EBL2 to one (A) of the two points.
(See Fig.4.3.)
In this figure, the starting point of EBL2 is represented as the cross cursor mark.
5 Turn the [EBL] control to move EBL2 to the other point (B).
(See Fig.4.3.)
6 Press to select VRM2 display and operation.
(VRM marker) will appear on a dotted-line of the EBL2.
To Next Page
