8 – 2
……8.1.1 Function Check on Test Menu ………………………………
The function status of this radar equipment can be checked on the TEST Menu.
1 Press .
The TEST Menu will appear.
2 Select any check item on the Menu and press to .
The list of items will appear.
1 Press or .
The TEST Menu will be closed.
( 1 ) Check of Memory, Safety Switch, Various Currents
and Voltages, and Communication Lines
( 2 ) Check of Panel
( 3 ) Check of ARPA
( 4 ) Check of Magnetron Current
( 5 ) Check with Performance Monitor
( 6 ) Error Logging Display
( 7 ) System Information Display
4.MAG CURRENT
OFF ON
OFF ON
TEST MENU
0.
EXIT
7.
1.
SELF CHECK
2.
PANEL TEST
3.
ARPA TEST
5.PM
6.
ERROR LOGGING
SYSTEM INFO
To Next Page
