A – 13
2.3 ISW (Interswitch) Menu
Refer to: (B) [ISW MENU 1 ••• 2-units (No.1 to No.6)]
(C) [ISW MENU 2 ••• 3-units (No.1 to No.6)]
(D) [ISW MENU 3 ••• 3-units (No.7 to No.12)]
The Interswitch Menu can be selected only when the radar system is set to on the standby mode.
Although the Interswitch Menu can be opened during transmission, the radar system will stop
transmission and enter the standby state automatically.
q Press .
ISW Menu (on display right)
The ISW Menu will appear
The Sub1 Menu will appear
Unit No. of radar sysmtem
Pattern No.
(2-unit system) , Set with the internal dip switches / (3-unit system)
The Number whose
background is dark filled is the
number currently connected.
The number surrounded by a
frame is the number to be
selected.
To Next Page
