A – 1
……JMA-9800 ARPA Series Radar System Composition ……………
Table A-1 S band System Composition
Equipment Type JMA-9833-SA JMA-9832-SA
Type of Scanner NKE-1079 (*1) NKE-1075 (*1)
Type of Performance Monitor NJU-63 NJU-63
Type of Transmitter-receiver Unit
NTG-3037
Type of Transmitter Unit NMA-446 NMA-487
Type of Receiver Unit NRG-88 NRG-222
Type of Display Unit NCD-4111 (*2)
*1 NKE-1079 (110 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø)
NKE-1079-D (110 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø) (Option with deicing heater collar)
NKE-1075 (100/110/115/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø)
NKE-1075-D (100/110/115/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø) (Option with deicing heater
collar)
*2 NCD-4111: Self-standing type
NCD-4111-T: Desktop type (NWU-228: Monitor Unit, NDC-1097: Control Unit,
NCE-7292: Keyboard Unit) (Option)
Note: The ARPA unit have the approbation by the Ministry of Transport Automatic equipment for
Prevention of collision JAS-9800.
Table A-2 X band System Composition
Equipment Type JMA-9823-7XA JMA-9823-9XA JMA-9822-6XA JMA-9822-9XA
Type of Scanner NKE-1059-7 (*1) NKE-1059-9 (*2) NKE-1052-6 (*3) NKE-1052-9 (*4)
Type of Performance Monitor
NJU-64 NJU-64
Type of Transmitter-receiver Unit
NTG-3027
Type of Transmitter Unit NMA-441
Type of Receiver Unit NRG-98
Type of Display Unit NCD-4111 (*5)
*1 NKE-1059-7 (7 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø)
NKE-1059-7D (7 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø) (Option with deicing heater
collar)
*2 NKE-1059-9 (9 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø)
NKE-1059-9D (9 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø) (Option with deicing heater
collar)
*3 NKE-1052-6 (6 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø)
NKE-1052-6D (6 ft 110/220 V AC 50/60 Hz 1ø, 220 V AC 50/60 Hz 3ø) (Option with deicing heater
collar)
APPENDIX
