3 – 20
3
3.3 PREPARATION
.
..
……Color Setting COLOR ……………………………………………
The colors of the Day/Night mode [DAY1, 2/NIGHT1, 2], system, background color outside the bearing
scale, background color inside the bearing scale, echoes, characters, dials, own ship’s track and radar
trails are set up.
Color Adjustment by Menu Operation
DAY/NIGHT - Register of DAY/NIGHT mode (the same function as [DAY/NIGHT] setting)
SYSTEM - System color adjustment
OUTER PPI - Adjustment of the background color outside the bearing scale
INNER PPI - Adjustment of the background color inside the bearing scale
ECHO - Adjustment of echo colors
CHARACTER - Adjustment of character colors
DIAL - Adjustment of dial color
OWN TRACK - Adjustment of the color of own ship’s track
TRAILS - Adjustment of the color of radar trails
1 Press .
The Main Menu will appear.
2 Press .
The Sub1 Menu will appear.
3 Press .
The Sub2 Menu will appear.
4 Press .
The COLOR Menu will appear.
To Next Page
